Moondrop Colorfly CDA M1 Portable DSD512 DAC HiFi USB Headphone Amplifier 3.5mm Audio/4.4mm Balanced AMP

Moondrop Colorfly CDA M1

Specification：
Model: CDA-M1
Independent op-amp chip: RT6863
USB connector: Type-C
Decoding format: PCM 32Bit/768kHz; DSD512/Native; DSD256/Dop
SNR: 120dB

THD + N:
-100dB@RL=600Ω, -1dB/high resistance/balanced
-98dB@RL=32Ω, 100mW/low resistance/balanced
-100dB@RL=600Ω, -1dB/high resistance/un-balanced
-98dB@RL=32Ω, 100mW/low resistance/un-balanced

Output level
2Vrms@RL=600Ω un-balanced output
4Vrms@RL=600Ω balanced output

Max. Output power
100mW@RL=32Ω un-balanced output
200mW@RL=32Ω balanced output
Frequency response: 20Hz-20kHz(+0.05dB/-0.4dB)
Dynamic range: 120dB
Firmware upgrade: support later upgrade

Package：
CDA-M1*1
Type-C data cable*1
Type-C to USB-A adapter*1
